This page includes a few links of internet visualization that i've been playing with..
I've been using a tool called aiSee to render parsed data from Route Views. I've also played with Wilma which can do 3d rendering, but to do this 19822 node, 42496 edge graphic was too intensive for the machine I had available.
| Description | image size | Graphic |
| Top 20 most interconnected ASNs | 2480x4736 png | 04-May-2005 |
| TBD | 2152x2948 png | 04-May-2005 |
| Global Interconnects (10 iterations) | 2424x2871 png | 04-may-2005 (10) |
| 15 iterations | 1944x2537 png | 04-may-2005 (15) |
| 30 iterations | 3248x4208 png | 04-may-2005 (30) [~30 min gen time] |
| aiSee datafile | 04_may_2005.gdl | |
| Weighted global interconnects | 3248x4078 png | 04-may-2005 (30) |
| " " | EPS 2 35M | EPS Source |
| aiSee datafile | 3.7M | ais.504.gdl |
Feedback to Jared Mauch aka jared at puck dot nether.net
